KOREA제품개요
제품사양
| ITEM | LINEBEAM 01 |
|---|---|
| luminous source | High power 2pcs*10w high intensity CREE LEDs |
| Operating Voltage | 9~60V (option : 10~110V) |
| Operating Temperature ( Degree Celsius ) | -40℃ ~ +80℃ |
| LED Power | 10W (20W option) |
| Lumen | 8000LM max. |
| Material of the case | Aluminum die-cast housing , PC lens Cover |
| Bracket | Stainless steel bracket |
| Vibration Condition | 9.3G at 55Hz |
| Water prbofe | IP68 |
| Weight(g) | main body : 293g bracket , screw : 65g |
| Color temperature | 6000K |
| Lift Time(MTBF) | 30000 hours |
| Light Color | Blue (option : Red Color) |
| Optional Beam | Arrow, Line |
| Beam shape | 30 degree spot beam |
| Reverse Protect | Rever Polarity Protected |
| Wire | Double Insulated Silicon Rubberized Wire |
| Measurement | 97(W) x 64(H) x 74(D) mm |
| Certificate | CE , IP68 , RoHs |
| Measuring method |
|---|
 |
 |
 |
